12" TRUSS
CHAIN MOTORS
GLOBAL TRUSS
20" TRUSS
30" x 20" TRUSS
48" x 24" TRUSS
PRE RIG TRUSS
• CLICK TO GET A RENTAL QUOTE ON THIS ITEM •
FABRICATED BY CERTIFIED TUV WELDERS
EQUIPPED WITH CONNECTING HARDWARE
3 7/8" (100mm) OVERALL WIDTH
3/4" (20mm) OUTER DIAMETER TUBING
1/4" (5mm) DIAGONAL BRACING
0.08" (2mm) WALL THICKNESS
Unit Weight 3 Lbs.
• SQ-F14-0.51.64ft (0.5m) MINI SQUARE SEGMENT
• SQ-F14-1.03.28ft (1.0m) MINI SQUARE SEGMENT
• SQ-F14-1.54.92ft (1.5m) MINI SQUARE SEGMENT
• SQ-F14-2.06.56ft (2.0m) MINI SQUARE SEGMENT
• SQ-F14-2.58.20ft (2.5m) MINI SQUARE SEGMENT
• SQ-F14-3.09.84ft (3.0m) MINI SQUARE SEGMENT
• CLICK TO GET A RENTAL QUOTE ON THIS ITEM •
ST-UJB-F14 - UNIVERSAL JUNCTION BLOCK
2 - 6 WAY UNIVERSAL CORNER
COMES WITH TWO CONNECTING SIDES
3 7/8" (100mm) OVERALL WIDTH
3/4" (20mm) OUTER DIAMETER TUBING
1/4" (5mm) DIAGONAL BRACING
0.08" (2mm) WALL THICKNESS
UNIT WEIGHT 2 lbs
• CLICK TO GET A RENTAL QUOTE ON THIS ITEM •
FABRICATED BY CERTIFIED TUV WELDERS
EQUIPPED WITH CONNECTING HARDWARE
11 7/16" (290mm) OVERALL WIDTH
2" (50mm) OUTER DIAMETER TUBING
3/4" (20mm) DIAGONAL BRACING
0.08" (2mm) WALL THICKNESS
UNIT WEIGHT Varies by length
IN STOCK to available RENT
TR-4076 1.64ft. (0.5m) TRIANGULAR SEGMENT BLACK
TR-4077 3.28ft. (1.0m) TRIANGULAR SEGMENT BLACK
TR-4079 6.56ft. (2.0m) TRIANGULAR SEGMENT BLACK
TR-4081 9.84ft. (3.0m) TRIANGULAR SEGMENT BLACK
• CLICK TO GET A RENTAL QUOTE ON THIS ITEM •
FABRICATED BY CERTIFIED TUV WELDERS
EQUIPPED WITH CONNECTING HARDWARE
11 7/16" (290mm) OVERALL WIDTH
2" (50mm) OUTER DIAMETER TUBING
3/4" (20mm) DIAGONAL BRACING
0.08" (2mm) WALL THICKNESS
UNIT WEIGHT varies on length
IN STOCK to available RENT
• SQ-41091.64ft. (0.5m) SQUARE SEGMENT
• SQ-41103.28ft. (1.0m) SQUARE SEGMENT
• SQ-41114.92ft. (1.5m) SQUARE SEGMENT
• SQ-4111-12504.10ft. (1.25m) SQUARE SEGMENT
• SQ-41126.56ft. (2.0m) SQUARE SEGMENT
• SQ-4112-2759.02ft. (2.75m) SQUARE SEGMENT
• SQ-41138.20ft. (2.5m) SQUARE SEGMENT
• SQ-41149.84ft. (3.0m) SQUARE SEGMENT
• SQ-411511.48ft. (3.5m) SQUARE SEGMENT
• SQ-411613.12ft. (4.0m) SQUARE SEGMENT
• SQ-411714.76ft. (4.5m) SQUARE SEGMENT
• SQ-411816.40ft. (5.0m) SQUARE SEGMENT
• CLICK TO GET A RENTAL QUOTE ON THIS ITEM •
ST-UJB-12 - UNIVERSAL JUNCTION BLOCK
FABRICATED BY CERTIFIED TUV WELDERS
EQUIPPED WITH CONNECTING HARDWARE FOR 2 SIDES
11 7/16" (290mm) OVERALL WIDTH
2" (50mm) OUTER DIAMETER TUBING
3/4" (20mm) DIAGONAL BRACING
0.08" (2mm) WALL THICKNESS
UNIT WEIGHT 17lbs
• CLICK TO GET A RENTAL QUOTE ON THIS ITEM •
SQ-4122 - 1.64ft. (0.5m) 2 WAY 120 DEGREE CORNER
FABRICATED BY CERTIFIED TUV WELDERS
EQUIPPED WITH CONNECTING HARDWARE
11 7/16" (290mm) OVERALL WIDTH
2" (50mm) OUTER DIAMETER TUBING
3/4" (20mm) DIAGONAL BRACING
0.08" (2mm) WALL THICKNESS
UNIT WEIGHT 18lbs.
• CLICK TO GET A RENTAL QUOTE ON THIS ITEM •
SQ-4123 - 1.64ft. (0.5m) 2 WAY 135 DEGREE CORNER
FABRICATED BY CERTIFIED TUV WELDERS
EQUIPPED WITH CONNECTING HARDWARE
11 7/16" (290mm) OVERALL WIDTH
2" (50mm) OUTER DIAMETER TUBING
3/4" (20mm) DIAGONAL BRACING
0.08" (2mm) WALL THICKNESS
UNIT WEIGHT 18lbs.
• CLICK TO GET A RENTAL QUOTE ON THIS ITEM •
BASE PLATE 30X30A - 30" X 30" ALUMINUM BASE PLATE FOR F24-F32-F33-F34-F44P
30" x 30" ALUMINUM BASE PLATE.
3/8" ALUMINUM THICKNESS
UNIT WEIGHT 35lbs.
• CLICK TO GET A RENTAL QUOTE ON THIS ITEM •
DT-DYNO WHEEL - CIRCULAR TRUSS TOPPER
ROUND TRUSS TOPPER FOR F34 SQUARE TRUSS
DIAMETER OF WHEEL 3.28 FT
UNIT WEIGHT - 30 LBS.
• CLICK TO GET A RENTAL QUOTE ON THIS ITEM •
DT-FXMT - FIXTURE MOUNT TRUSS TOPPER
FOR F34 SQUARE TRUSS PORTABLE FLOOR STAND
UNIT WEIGHT 7 Lbs.
